Attachments for TMK Tree Shear
Discover the Power of TMK Tree Shear Attachments: A Revolution in Tree Management
TMK Tree Shear Attachments
Easy Installation
Effortless Installation for Every Machine - 4 in 1
At TMK, we understand the importance of efficiency and flexibility in the field. Our Tree Shear attachments are designed for easy installation without the need for additional hydraulics. With a single, two-way hydraulic circuit, you can operate up to 4 functions.
Our innovative design allows for retrofitting on a wide range of machinery, including harvesters, log loaders, and agricultural tractors. Say goodbye to complex installations—TMK attachments empower you to use exactly the equipment you need for any job.
Collector Gen2
The Most Popular Attachment: Collector Gen2
Introducing the Collector Gen2, the unrivaled choice for efficient thinning in young forests. With the Collector, you can easily cut and collect thin trunks without lifting the boom after each cut, allowing for reduced fuel consumption and maximized shear capacity.
Enhanced design features, including reinforced mechanical parts and improved geometry, ensure reliability in tough conditions. Choose between two control methods—Easy Control for automatic operation or Full Control for manual precision. The Collector Gen2 is compatible with TMK 200, TMK 250, TMK 300, and TMK 400 models.
BrushGrapple
Precision Cutting with the BrushGrapple
The TMK Tree Shear BrushGrapple is engineered for neat and precise cutting of even the smallest trees. Its uniquely sharpened bottom blade effectively eliminates gaps, promoting a scissor-like cutting motion that ensures no soil or debris harms your wood chipper.
This essential attachment is a staple for most TMK shears, providing the versatility needed for diverse tree management tasks.
Fixed Tilt
Controlled Cutting with the Fixed Tilt
The TMK Tree Shear Fixed Tilt meets the needs of operators working in areas lacking tiltrotators. It offers a comprehensive tilting angle of up to 180 degrees, enabling controlled removal of branches and problem trees.
Designed for TMK 300 and TMK 400 units
Rotator
Agility in challenging environments wit the Rotator
The R-series (Rotator) means that the tree shear is directly equipped with a rotator to make the operation more agile in challenging environments. The strengths of the R-series shears are its agility and efficiency and a wide range of other attachments.
The R-series shears are equipped with a complete rotator structure which includes a heel before the rotator to help moving the machine by taking support from the ground. It gives full 360 degrees rotation when the shear can be lined up even with downward hanging branches.
The Rotator is available for TMK 200, TMK 300 and TMK 400.
Solid Extension
Maximize Safety and Reach with the Solid Extension
The Solid Extension is perfect for navigating difficult worksite terrains and safely handling problem trees. By adding approximately one meter (3 feet) of reach, this attachment enhances the functionality of your TMK Tree Shear, particularly when paired with a Delimber.
Designed for use with a tiltrotator, the Solid Extension protects hydraulic hoses and minimizes damage to branches during operation. Available in two sizes, it allows for quick removal and compatibility with various TMK models.
Delimber
Streamline Your Timber Operations with the Delimber
The TMK Tree Shear Delimber is the perfect solution for optimizing energy wood use, particularly in Nordic countries where demand for trimmed timber is high. This attachment allows you to efficiently trim your timber using your existing machinery, eliminating the need for a separate trimming machine.
With a diamond-shaped slot for smooth operation and effective bark scraping, the Delimber enhances the drying process and calorific value of your timber. Compatible with all TMK Tree Shear models (excluding TMK 150), it operates without rolls or electricity for ease of use and retrofitting.
Tree Support
Precise control with Big trees: Tree Support
Almost half an meter tall Tree Support gives more control and safety for handling big and tall trees. Higher support on the back of the shear prevents trees leaning towards the machine by giving more control for accurate tree landing.
The Tree Support is only available for our biggest model TMK 400. The bolted on design ensures easy installation even to the existing shears excluding TMK 400s with Collector.
Hydraulic Extension Gen2
Precision and Reach Combined: Hydraulic Extension Gen2
Our second-generation Hydraulic Extension provides a remarkable 1.6 meters of hydraulic reach while maintaining compact capabilities. Featuring a 165-degree tilt unit, this extension allows cutting closer to the machine and parallel to the ground.
With new protective covers and easily accessible maintenance features, the Hydraulic Extension Gen2 ensures smooth and efficient operation for TMK 200, TMK 250, and TMK 300 machines. Get the extra reach you need to tackle challenging tasks effortlessly!
TMK Loader Extension
Loading and extra reach with a TMK Loader Extension
Designed to meet one of our most requested features: enhanced loading capabilities! The wide opening grapple arm can be controlled via a separate hydraulic circuit or from the same hydraulic circuit the Tree Shear using by an electric diverter valve. The wide trajectory makes it effortless to handle large tree stacks, even in tight spaces.
But it offers more than just loading power! The Loader Extension extends the reach of the Tree Shear and works seamlessly with a tiltrotator, allowing you to cut behind trees and create side piles without repositioning your machine. It also functions as a sturdy heel to help nudge obstacles out of the way.
Available in two versions—Solid and Tilt—the Solid version is perfect for adding loading capabilities and extra reach to TMK 300 or TMK 400 models. If you're ready to elevate your performance, opt for the Tilt version, which maximizes efficiency and precision by keeping the shear in the optimal position for cutting and delimbing when tilting from the end of the extension instead of using the bucket cylinder of the machine.
Note: The Tilt version requires a new shear frame and is available for TMK 250 and TMK 300; consult your dealer for fitting options.
Adapter Plate
The Key to Versatility: Adapter Plate
The TMK Tree Shear Adapter Plate is essential for enhancing the adaptability of your shear. By using an Adapter Plate instead of welding directly onto the shear, you enable easy machine transfers and simplify resale options if needed. The back of the shear is designed in a perfect angle to ensure pleasant operation.
This thoughtful bolted on design ensures seamless interchangeability with minimal hassle, making your TMK Tree Shear investment even more valuable.
Splitting Blade
Efficient Trunk Splitting with the Splitting Blade
The TMK Tree Shear Splitting Blade is designed to assist with splitting large tree trunks, promoting better drying of timber. It attaches quickly with three bolts, allowing you to maximize the utility of your tree shear effortlessly.
Improve your timber management capabilities and simplify your workload with this highly functional attachment.
Heel
Enhanced Stability with the Heel Attachment
The Heel attachment provides vital support and stability when navigating challenging terrains. Affixed to the back of the shear, it ensures reliable movement regardless of machine size and can even be used for tree stump removal.
Pre-installed within the Solid Extension, the Heel enhances operational efficiency while improving machine handling.
